3-axis/4-axis/5-axis 1500800700 cnc milling machine(heavry+line rails)

Product Item：Yongshuo YSL-1580

Bed size:1700*800mm

Xyz traveling distance:1500*800*700mm

Toolcharger: 24 Tools

Unit price: 60000-70000USD

1. Products Name:

3-Axis/4-Axis/5-Axis 1500*800*700mm CNC Milling Machine(Heavry+Line Rails)

2. Basic Technical Data:

Technical Data：	Yongshuo YSL-1580
Bed Size：	1700*800mm
X-Axis Traveling Distance：	1500mm
Y-Axis Traveling Distance：	800mm
Z-Axis Traveling Distance：	700mm
XYZ Axis Model & Applying：	XY-AXIS LINEAR RAIL Z-AXIS HEAVRY RAIL(HUGE MILLING & CUTTING FORCE) Besides being used for processing aluminum, flexible steel, copper, non-ferrous metal parts, alloy parts, plastic parts, gypsum parts, acrylic parts, dies, hand plates, etc. Specially used for processing steel materials, stainless steel materials,, non-embroidered steel & cemented carbide materials, high hardness metals and alloys. It is a multi-functional and multi-purpose CNC machine center.
Spindle Motor Power：	15.0KW/18.5KW
Spindle Speed：	0-8000 rpm belt connect
Tool Changer(Tool Magazine)：	24 Arm Type; BT50
Control System：	FANUC,MITSUBISHI,SIEMENS,SYNTEC Four-axis function & five-axis function expansion interfaces by default intergrated and built-in in system. Upgrade easily, Plug & play
Configurable Rotary Table:	5-axis cradle rotary table,digital control 4-axis rotary table, disk tailstock rotary table,thimble tailstock rotary stable, or synchronous double-head rotary table,etc Φ125mm-Φ500mm
Machine Weight:	13000KG
