Description
1. Products Name:
Veritcal CNC Milling Machining Tool With Horizontal 5-axis Rotary Table
Horizontal 5-axis CNC Milling Machine Center
DMU65 CNC Milling Machine Center
2. Basic Technical Data:
|
Main Technical Data |
Item |
Description |
|
Machine Model |
|
YSWZ-650 |
|
CNC Controller |
CNC Control System |
SIMENS 840D 5axis |
|
XYZ Axis Traveling Distance |
X-axis Valid Processing Distance |
820mm |
|
|
Left Traveling Distance |
500mm |
|
|
Right Traveling Distance |
320mm |
|
|
Y-axis Valid Processing Distance |
520mm |
|
|
Z-axis Valid Processing Distance |
460mm |
|
Workbench |
Valid working size |
650*650mm |
|
|
Worktable to Spindle Nose(MM) |
220-680 |
|
|
Max.loading Weight |
600kg |
|
|
Workbench Surface Process |
Super-hard anti-scratch & wear resistance quenching process |
|
|
Groove Width/Spacing(MM) |
5-18*100 |
| Spindle |
Spindle RPM |
10000-12000rpm |
|
|
Spindle Speed |
Variable Speed Adjust(Stepless) |
|
|
Spindle Taper |
SK40/BT40 |
|
|
Spindle Connect Mode |
Direct Connect Digital drives |
|
|
Spindle Cooling Mode |
Spindle Surround Cooling & Center Cooling (Coolant Through Spindle) |
|
X,Y,Z Axis Working Speed(M/MIN) |
Moving Speed(X/Y m/min) |
360000 |
|
|
Moving Speed(Z m/min) |
360000 |
|
|
Cutting Speed(X/Y m/min) |
10000 |
|
Guide Rails, Rods, Screws, and Sliders |
XYZ Ball Screws Specification |
4512 |
|
|
X Linear Rails Specification |
MSA45LA |
|
|
YZ Linear Rails Specification |
MSA45LA |
| Motors |
Spindle Motor |
11kw |
|
|
Feeding Motors |
3kw |
|
ATC System(Tool Magazine) |
Taper Model |
MAS BT40/SK40 |
|
|
Tool Qty.(Auto Tool Changer) |
24 |
|
Horizontal 5-Axis Rotatry |
Rotation (C-axis) |
Rotation (C-axis) 360o |
|
|
Swivel Range(A(B)-axis) |
-50 to +1100 |
|
Work Request |
Power Supply Input |
3-phase, 380v,50Hz |
|
|
Air Pressure |
6-Bar |
|
Covering Area |
Size |
2700*2350*2470mm |
| Machine Weight | Net.Weight | 10,000kg |
| *** |
|
|
3. Payment methods
By T/T in advance;
Down payment: 30% of total amount. Before delivery, 70% balance need to be paid.
4. Delivery time:
By Sea
Delivery time: about 25-30 days.
5. Quality Warranty:
SuperImage offers “3R” quality warranty for our CNC Mach-”Replacement, Return, and Refund” will be guaranteed for inferior quality products.
