Description
1. Products Name:
(4-Axis) 1000mm*1200mm High-speed CNC Wire Cut Discharge Machine
(4-Axis) Advance High-speed CNC Wire Cut EMD 1000mm*1200mm
(4-Axis) Advance High-speed CNC WEDM 1000mm*1200mm
2. Basic Technical Data:
TECHNICAL DATA
WEDM-YSDK77100
CONTROL SYSTEM & AXIS QTY.
AUTOCUT, 4 AXIS
XY AXIS TRAVELING DISTANCE
1000*1200MM
WORKTABLE SIZE
1060*1500MM
MAX.LOADING WEIGHT OF WORKTABLE
2000KG
MOTOR DRIVING MODE
STEPPING MOTOR DRIVE
MACHINING SURFACE ROUGHNESS
Ra≤2.5UM
MACHINING PRECISION
0.02UM
MAX. CUTTING THICKNESS
900MM
MAX.CUTTING SLOPE/WORKPIECE THICKNESS
+30/100
MAX.CUTTING SPEED
≥12000MM2/HOUR
STABLE MACHINING SPEED
10000MM2/HOUR(2-3 TIMES THAN THAT OF ORDINARY)
SCREWS RUNNING SPEED
12MM
DIAMETER OF ELECTRODE WIRE
Φ0.1-0.25MM
MACHINE RUNNGING POWER
1.5KW
MAX.MACHINING CURRENT
8A
MACHINE SIZE
3000MM*2450MM*1967MM
MACHINE WEIGHT
4500KG
HARDWARE CONFIGURATION & INTERFACE
SCHNEIDER ELECTRIC,USB,LAN/RS232
OPERATION PANEL & LANGUAGE
ENGLISH,JAPAN,RUSSIA,ETC
3. Payment methods
By T/T in advance;
Down payment: 50% of total amount. Before delivery, 50% balance need to be paid.
4. Delivery time:
By Sea
Delivery time: about 25-30 days.
5. Quality Warranty:
SuperImage offers “3R” quality warranty for our CNC WEDM-”Replacement, Return, and Refund” will be guaranteed for inferior quality products.
